Dell Precision 7560 | Intel Xeon W-11855M | 16 GB RAM| 512 SSD| Nvidia RTX A2000(4GB)
Dell Precision 7560
Intel Xeon W-11855M| 16GB RAM DDR4 | 512GBSSD NVMe | NVIDIA RTX A2000 4GB
| Category | Detailed Specification |
|---|---|
| Processor | Intel Xeon W-11855M (11th Gen, Tiger Lake) |
| - Core/Thread Count | 6 Cores / 12 Threads |
| - Base Frequency | 3.19 - 3.20 GHz |
| - Max Turbo Frequency | 4.8 GHz (4,789 MHz) |
| - Smart Cache | 18 MB L3 Cache |
| - TDP | 45 W (configurable up to 35W cTDP down) |
| Memory (RAM) | 16 GB DDR4 SDRAM |
| - RAM Speed | 3200 MHz (supports ECC memory with Xeon) |
| - Form Factor | 4x SODIMM slots |
| - Max Supported RAM | Up to 128 GB |
| Storage | 512 GB NVMe SSD |
| - Storage Type | M.2 2280, PCIe Gen 4 x4, NVMe |
| Dedicated Graphics | NVIDIA RTX A2000 4 GB |
| - Video Memory | 4 GB GDDR6 |
| - Memory Interface | 128-bit |
| Integrated Graphics | Intel UHD Graphics (integrated into Xeon processor) |
| Platform | Mobile Workstation |
| - Chipset | Intel WM590 |
Ports & Connectivity Features
| Port / Feature Category | Detailed Specification |
|---|---|
| USB Type-C / Thunderbolt | 2x Thunderbolt 4 ports (USB-C, 40 Gbps, DisplayPort, Power Delivery) |
| USB Type-A | 2x USB 3.0 (3.2 Gen 1) ports |
| Video Output | 1x HDMI 2.1 port, 1x Mini DisplayPort 1.4 |
| Ethernet | 1x RJ-45 Gigabit Ethernet (Gb LAN) |
| Audio | 1x headphone/microphone combo jack (3.5mm) |
| Card Reader | 1x SD card reader (full-size, UHS-II supported) |
| Smart Card Reader | Optional smart card reader available |
| Wireless | Wi-Fi 6 (802.11ax), Bluetooth 5.2 |
| Power | 1x dedicated AC power connector (130W-180W adapter) |
| Security | 1x Wedge-shaped lock slot, optional Smart Card Reader, TPM 2.0 |
| Webcam | FHD (1080p) IR camera with Windows Hello support |
| Keyboard | Backlit keyboard with numeric keypad (numpad) |
1) Processor (Professional Performance)
Engineered for demanding workflows, this Dell Precision 7560 is powered by an 11th Gen Intel Xeon W-11855M processor. With 8 cores and 16 threads reaching speeds up to 4.80 GHz, it provides the high-octane performance necessary for complex simulations, data analysis, and heavy multitasking.
2) Memory & Storage (Data-Intensive Workloads)
Tackle massive datasets with 32GB of high-speed DDR4-3200 RAM, ensuring seamless transitions between professional design and rendering software. Paired with a lightning-fast 2TB PCIe NVMe M.2 SSD, you get exceptionally short boot times and near-instant access to large project files and asset libraries.
3) Display (True Color Accuracy)
Visualize your creations with stunning clarity on the 15.6-inch 4K UHD display. Offering 100% Adobe RGB color gamut and a brilliant 600 nits of brightness, this HDR600-certified panel delivers pixel-perfect precision for photographers, video editors, and CAD designers.
4) Graphics (ISV-Certified Power)
Power through professional applications with the NVIDIA RTX A4000 GPU and 8GB of GDDR6 VRAM. This workstation-grade graphics solution is certified for demanding ISV applications, enabling you to render complex 3D models, manipulate large assemblies, and develop AI models with real-time ray tracing and AI acceleration.
5) Battery Life & Charging (Staying Productive)
The Dell Precision 7560 features a high-density 6-cell battery. With ExpressCharge Boost, you can get up to 35% charge in approximately 20 minutes, getting you back to critical tasks quickly when you are away from your desk.
6) Ports & Connectivity (High-Speed Hub)
Eliminate the need for dongles with a comprehensive port selection, highlighted by two Thunderbolt 4 ports for high-speed data transfer and multi-4K display support. The system also includes HDMI 2.1, Mini DP 1.4, and a full-size RJ45 Ethernet port for stable, high-speed network connectivity.
7) Build Quality & Weight (Rugged Mobility)
Encased in a durable Titan Gray aluminum chassis, this mobile workstation offers a premium, tank-like feel that withstands the rigors of travel. Despite its robust engineering and starting weight of just 5.49 lbs, it provides a balance of professional durability and practical portability
